CONNECTED CAM™ 2/3-INCH BROADCAST CAMCORDER

GY-HC900CHU

Built-in 2.4GHz 5GHz / 2/3-inch 3CMOS / Bayonet mount for 2/3 inch lens / HD 1920x1080 / GEN Lock / 3G-SDI x1 input / 3G-SDI x2 output / EFP and studio installations / ND Filter


  • SSD recording option
  • HDR (High Dynamic Range)
  • SRT Protocol

Warranty

Labor: 1 year

Parts : 2 years

Extraordinary camera Performance

The heart of the GY-HC900 is a production-quality imaging system that begins with a B4 mount lens. The camera adapts to a variety of lenses and automatically corrects for aberration. Three 2/3-inch CMOS sensors, combined with an F1.4 prism, produce full HD images with excellent sensitivity of F12 at 60Hz (extended mode) and a high SNR of 62dB (standard). JVC has paid particular attention to dynamic range and provides an HDR mode for expanded creative expression.

A 4-position optical filter compensates for a variety of lighting conditions. Positions are: 1 (clear), 2 (1/4 ND), 3 (1/16 ND), and 4 (1/64 ND).

Memory card Recording

Dual memory card slots are provided for standard SDHC/SDXC media. Flexible recording options include redundant, relay and backup modes. For contribution quality, the camera supports recording in the ProRes HD422 format to a plug-in SSD module (optional). The GY-HC900 also supports both the popular MPEG-2 35/25Mbps format, widely used by television broadcasters, and the more efficient .MOV H.264 format capable of delivering production quality 1080/60p 4:2:2 10-bit recordings. In this mode, recordings can be made at frame rates up to 120fps for ultra-smooth slow motion effects. The camera also records proxy resolution video clips for off-line editing or on-line posting.

ProRes 422 RECORDING TO SSD

Slide in an optional KA-MC100G SSD module, and record in the Apple ProRes 422 HD format. ProRes offers virtually lossless intra-frame compression and speeds up post production. The KA-MC100G accepts standard SATA M.2 SSD memory.

SSD memory can also be used for backup recording. While the Rec trigger is used to REC and STOP recording on one SD card (Slot A), the other SD card (Slot B), or "EXT" (SSD), can act as a continuous backup that overrides the pause function. A 2-terabyte SSD drive will provide over 50 hours of backup capacity when recording in the 70Mbps XHQ (.MOV) format.

The Industry's Most Connected Camera

JVC has taken connectivity to the next level with the GY-HC900. The camera incorporates a new processing engine that enables recording and low latency streaming, and simultaneous decoding for return video and IFB. Talent in front of the camera can engage in a 2-way interview with return video and audio while streaming live to air—all of this without any external boxes or backpacks. Depending on the mode, latency can be low for both outgoing and incoming video. Cellular bonding takes place with the optional snap-on SFE-CAM module, or with a Wireless LAN connection to one of our bridge units.

SRT: QoS (Quality of Service) Technology

SRT (Secure Reliable Transport) is an open source video transport protocol that enables the delivery of high-quality and secure, low-latency video across the public Internet. SRT optimizes streaming performance across unpredictable networks with secure streams and easy firewall traversal, bringing the best quality live video over the worst networks. It accounts for packet loss, jitter, and fluctuating bandwidth, maintaining the integrity and quality of your video.

SRT provides end-to-end security, resiliency and dynamic endpoint adjustment based on real-time network conditions to deliver the best video quality at all times on any network.

SRT is built-in and can be dynamically adjusted for optimal stream performance and quality. Automatic Repeat Request (ARQ) is included with SRT. End-to-end 128/256 bit AES encryption makes sure your content is protected from contribution to distribution.

SRT features How Details
STABILITY:
Delivers broadcast-quality video over the Internet. Resilient to network congestion, high jitter, and packet loss.
Error
Correction
ARQ When packets are lost, the SRT decoder requests an encoder (camera) to resend lost data to eliminate potential video dropouts and artifacts. Up to 30% of data loss can be recovered.
FEC Forward Error Correction adds redundant data to the stream to be used to recover packets lost due to unstable connection, Internet congestion, and high jitter.
SECURITY:
Protects video channel from unauthorized access. Provides extra security when moving video over public networks.
Encryption Stream ID The SRT decoder only accepts the streams with embedded, encoder specified Stream ID. All other streams are ignored. The single port can be utilized to receive multiple streams differentiated by unique Stream IDs.
AES The entire SRT stream is encrypted with the industry-standard AES-128/256 standard. The "passphrase" is required on both encoding and decoding sides.
SYNCHRONIZATION:
Multicamera SRT streams synchronization for REMI.
Embedded
Timecode
NTP Multiple cameras TC can be synchronized with the NTP server via LAN or Wi-Fi Internet connection.
LTC End-to-end remote cameras synchronization solution with CONNECTED CAM Studio KM- IP4000/6000 series of video switchers.
VITC Industry-standard TC compatible with Haivision, VITEC, and other decoders.

KA-EN200 H.265/HEVC Encoder

With firmware version v0300, the GY-HC900 streams using the highly efficient HEVC/H.265 compression format which delivers broadcast quality streams at 50% of the normal bitrate, or contribution quality 4:2:2 10-bit streams at higher bitrates. The optional KA-EN200 encoder is required for H.265/HEVC operation.

The GY-HC900 is equipped with Multiple-Input Multiple-Output (MIMO) Wireless LAN technology for high speed, long range communications.

For studio and EFP operation, JVC offers the flexible FS-900 camera module which attaches directly without cables and feeds a 3-in-1 base station.

Broadcast Graphic Overlays

With v0300 firmware, the GY-HC900 is now the first 2/3-inch camcorder to offer lower third and full screen broadcast graphic overlays. Graphics can be either added on-the-fly using a smartphone or tablet, or pre-loaded from an SD card. This feature allows the camera operator to generate live streams that include a television station logo, without using a separate character generator.

Web API Command list

The following is link to command list document.

JVC Camcorder Web API Reference Version

  • Three advanced 2/3-inch CMOS image sensors for high sensitivity: F12 @ 60Hz
  • HDR (High Dynamic Range) (Hybrid Log Gamma)
  • Industry standard B4 lens mount
  • Signal-to-noise ratio 62dB (standard)
  • Dual SDXC media recording
  • ProRes HD422 10-bit recording to optional SSD (v0300)
  • 50 Mbps 4:2:2 10-bit recording (H.264) to SDHC/SDXC cards
  • Standard MPEG-2 recording up to 35 Mbps
  • 1080p slow motion recording (120fps)
  • Records Sports Exchange Standard formats (1080/720p)
  • Snap-on SFE-CAM bonded LTE transceiver (USB or RJ45 connection)
  • Built-in wireless LAN (2.4GHz/5GHz), high speed MIMO with dual external antennas
  • 3G-SDI (x2) outputs
  • 3G-SDI input for pool feed
  • HDMI output
  • Ethernet LAN (RJ45)
  • USB host for network function
  • Time code IN/OUT
  • Genlock input
  • XLR audio input (x3) and output
  • DC Power out connection (x3)
  • Advanced low latency (<500 ms) streaming up to 20Mbps (H.264)
  • HEVC/H.265 streaming possible with optional KA-EN200 plug-in encoder (v0300)
  • Stream camera or pool feed signal
Technical Specifications
Manuals
Technical Specifications
Camera Front-End Specifications
Image Sensor (inch)
2/3-inch CMOS
Number of Sensors
3
Mega Pixels
2,2
Sensitivity in F at 2000 Lux
F 12
S/N in dB
62
Synchronization External
Yes, and internal
Genlock
Yes
Shutter speed
1/3 to 1/1000, AUTO
Color Matrix adjustment
Yes
HDR (High Dynamic Range)
Yes
LOG Mode
Yes, J-LOG HLR
Optical Specifications
Lens mount
B4
Built-in ND Filters
3 Filters: 1/4, 1/16, 1/64
Recording Formats
Media
SDHC/SDXC memory card x 2
SSD recording option
Yes
Media Class
HD: Class 6/10 SD/Web: Class 4
Recording slots
2
File Format MOV
Yes
File Format MP4
Yes
File Format MXF
Yes
Video Codec MPEG2 Long GOP
Yes
Video Codec MPEG4 AVC/H264 4K/HD
Yes
Video Codec H264 (SD)
Yes
Recording specials
4:2:2 HD Record (H.264,50Mbps), 120Fps Slomo
Simultaneous recording on 2 cards
Yes
Simultaneous recording in 2 modes
Yes
Resolution 1920 x 1080
Yes, 60p/50p/30p/25p/60i/50i
Resolution 1280 x720
Yes, 60p/50p/30p/25p
Resolution 720 x 576
Yes, 50i
Resolution 720 x 480
Yes, 60i
Resolution 960 x 540
Yes, 30p/25p/24p
Resolution 640 x 360
Yes, 60p/50p/30p/25p
High Speed Recording
Yes
High Speed Recording Modes
120Fps
Recording Data rate 1
1920x1080 MPEG-4 AVC/H.264 10 Bit 4:2:2 35MBit to 50 MBit
Recording Data rate 2
1920x1080 MPEG-2 25Mbit to 35 MBit 4:2:0
Recording Data rate 3
other MPEG-2 25MBit to 35 MBit 4:2:0
Recording Data rate 4
1280x720 MPEG-4 AVC/H.264 4:2:2 10 Bit 50 Mbit
Recording Data rate 5
others MPEG-4 AVC/H.264 4:2:2 level: 4,1 1,2 MBit to 35 MBit
SD Recording
Yes
Over / Under Crank
Yes
Pre Rec (retro) recording
Yes
Audio Channels
4
IP Section of the Product
IP Main Connection
USB A Host and RJ45 direct Ethernet
IP Connection supports
Ethernet, WIFI - and LTE USB Adapters
IP LTE Channel Bounding
Yes, with future optional device
Built-in WIFI
Yes
Built-in Wi-Fi frequency band support
2,4GHz and 5GHz with MIMO
IP Features Live-Streaming
Yes
IP Features Remote
Yes, via RM-LP100 or Web-Browser no apps needed
IP Features FTP
Yes, Different protocols
IP Features Auto FTP Upload
Yes
IP Features Meta-Data
Yes, Local and Remote editing and data exchange
IP Features IFB (Audio-Return via IP)
Yes, with optional Audio encoder AAC Format
IP Video Return stream
Yes
Live-Streaming Bitrates
1920 x 1080 (59.94p/50p) 20 – 8 Mbps, (29.97p/25p) 20 – 3 Mbps, / 1920 x 1080 (59.94i/50i) 20 – 3 Mbps,
/ 1280 x 720 (59.94p/50p) 20 ? 3 Mbps,/ 1280 x 720 (29.97p/25p) 8 ? 1.5 Mbps,/ 720 x 480 (59.94i), 720 x 576 (50i) 8 – 0.3 Mbps, / 640 x 360 (59.94p/50p) 3/1.5 Mbps, / 640 x 360 (29.97p/25p) 3 – 0.3 Mbps
Live-Streaming Protocols
RTMP, MPEG2-TS/UDP, MPEG2-TS/TCP, MPEG2-TS/RTP, RTSP/RTP, Zixi
SRT Protocol
Yes
Live-Streaming Single cast
Yes
Live-Streaming Multicast
Yes
Live-Streaming (encoding) for Poolfeed signals
Yes
Live-Streaming and simultaneous REC
Yes
FTP upload during REC
Yes, Auto upload after rec/pause activation
LAN Terminal
Yes, RJ 45 1000Base-T
Input / Output Connections
OUT HDSDI
Yes, 3G HDSDI by 2
OUT HDSDI Format max.
1080/60p,50p 10 Bit 4:2:2 EE
OUT HDMI
Yes
OUT HDMI Format max.
1920x1080 60/50p 10 Bit
OUT AV
Yes, Composite BNC
OUT Audio Line
Yes, XLR
OUT Audio Headphone
Yes, 1 times 3.5mm mini jack
IN Poolfeed HDSDI
Yes, 3 Gbit HDSDI
IN Genlock
Yes
IN Audio XLR MIC/LINE
Yes, 2x 3 PIN XLR & 1x 5 PIN XLR supports LINE and MIC Level with +48V
External Lens connector
Yes, 12 pin standard
Time code IN/OUT
Yes, 2 x BNC
Wired remote IN
Yes, Mini i 6 PIN DIN
Wired remote IN
Yes
USB HOST
Yes
USB Data Exchange (Storage)
Yes
System Connector
Yes, 68 Pin
EVF Connector
Yes, 26 Pin system connector
Option Slot
Future expansion slot for LTE / SSD / Encoders
Wireless Audio Receiver slot
Yes
Wireless Audio Receiver Slot Format
UNISLOT
EVF and LCD
Operation Panel Type
LCD
Operation Panel Resolution
QHD 960x540 16:9
Operation Panel Size diagonal in inches
3.5
Electronic Viewfinder (EVF) Type
OLED
Electronic Viewfinder (EVF) Resolution
WVGA 854x480 16:9
Electronic Viewfinder (EVF) Size diagonal in inches
3.26
Power and Enviroment Spec´s
Power DC
Yes, 12V (11V – 17V)
Power consumption
Approx. 38W (during single recording at factory default settings while using the viewfinder)
Physical Information
Weight in lbs
8.7 lbs
General Editing Note
NOTE:
Simulated pictures.The values for weight and dimensions are approximate .E.&O.E. Design and specifications subject to change without notice.
