ULTRA WIDE ANGLE 4K60P NDI/HEVC AUTO-TRACKING PTZ CAMERA with 3G-SDI/HDMI/USB/IP OUTPUT (BLACK)

KY-PZ510NBU NEW

NDI HX3 / 4K 60p50p / SRT / RTMPS / HEVC / H.265 / 80-degree FOV / Auto Tracking / USB UVC Cam


  • NDI|HX3 Protocol
  • SRT Protocol
  • H.265 Codec
  • 4K Live Streaming

Warranty

Labor: 1 year

Parts : 1 year

New Advanced Auto Tracking

SMART (Subject Movement And Recognition Tracking)

Five Auto Tracking Settings

Standard, Area, Stage, Wide Area and Fine Adjustment

"Subject Movement and Recognition Tracking Auto Tracking" now has five new function settings to provide intelligent operation for sophisticated and engaging productions.


In the Standard mode, you can set the headroom spacing above the subject.

In the Area mode, The camera captures the Area frame where the target subject is visible. When the subject moves to an adjacent Area, the camera pans to the new Area.

Please take a look at the Five New SMART Auto Tracking Settings brochure.

The Power of NDI with JVC

Command list

The following are links to command list documents.

JVC Camcorder Web API Reference Version, HTTP Command Support, PTZ Standard Command List



NDI HX3

The camera has the NDI HX3 mode which delivers maximum quality and near zero latency transmission at a reduced bandwidth compared to NDI High Bandwidth.

NDI SDK Version: NDI 5

  • This camera (built-in NDI HX3) supports NDI 5.
    NDI 5 support Reliable UDP (RUDP) transmission protocol. RUDP ensure reliability through retransmission with high-speed communication, such as UDP.

    Super-Wide 80-degree Field of View

    Focal length is 3.47mm to 41.7mm (21.8 mm to 261.8mm, 35mm equivalent). Super-wide horizontal angle
    of view is 80° which is ideal for use in offices, classrooms, studios, event facilities, sports venues and houses of worship.

    Please take a look at the PTZ General brochure.

    4K60p H.265/HEVC Streaming

  • Ultra-high resolution 4K60p streaming is ideal for viewing sports and events. Highly efficient H.265/HEVC compression technology also produces similar or better image quality than H.264 at 50% of the bitrate.

    Multi-Slice Encoding Technology

    Multi-slice encoding technology increases performance and efficiency while reducing latency to achieve optimal image quality of live transmissions in 4K60p HEVC mode.

    IP Address Display

    Rear Panel

    Upgrade Your JVC PTZ Camera Firmware

    • YUV 4:2:2 12bit: HDMI output supports YUV 4:2:2 12bit and RGB 4:4:4 8bit.
    • 4K 60p50p streaming to YouTube: You can stream 4K(2160p60) from KY-PZ510/N to YouTube.
    • UVC (USB Video Class)
    • Multi-Camera synchronization with VITC and NTP
    • Save setup files: You can save the menu settings as a setup file on a PC.
    • Still image capture
    • H.264/H.265/Motion JPEG and dual streaming
    • 2-color tally useful for studio shooting
    • Internal Microphone
    Technical Specifications
    Manuals
    Technical Specifications
    Camera Front-End Specifications
    Image Sensor (inch)
    1/2,8 Inch CMOS
    Number of Sensors
    1
    Mega Pixels
    8.40
    Gain in dB
    0 to 45
    S/N in dB
    55
    Min. Illumination
    0.5Lux
    Shutter speed
    1/25 to 1/10000
    Optical Specifications
    Lens mount
    Internal
    Optical Zoom in 4K x times
    12
    Digital Magnification x times
    16
    Lens F Number
    1.8 to 3.7
    Lens ratio from / to
    3.4mm to 41.6mm
    Lens ratio equivalent to 35mm
    21.8mm to 261.8mm
    Auto Focus
    Yes
    PTZ Head Features
    PAN Angle in degree +/-
    162.5
    PAN Speed with AC Adapter max degree/sec.
    80.5
    PAN Speed with POE+ max degree/sec.
    80.5
    TILT Angle in degree
    -30 to 90
    TILT Speed with AC Adapter max degree/sec.
    49
    TILT Speed with POE+ max degree/sec.
    49
    Preset Positions
    255
    IP Section of the Product
    IP Main Connection
    Ethernet LAN RJ45 1000Base-T with POE+
    IP Connection supports
    Ethernet
    IP Features Live-Streaming
    Yes
    IP Features Remote
    Yes, via RM-LP100 or Web-Browser no apps needed
    Video Compression Codecs
    3
    H.265 Codec
    Yes
    H.264 Codec
    Yes
    MJPEG Codec
    Yes
    Live-Streaming Bitrates
    1~60 Mbit/s
    Live-Streaming Protocols
    NDI|HX, SRT, RTMP, RTMPS, RTSP
    SRT Protocol
    Yes
    NDI|HX3 Protocol
    Yes
    Live-Streaming Single cast
    Yes
    Live-Streaming Multicast
    Yes
    Live-Streaming Resolution
    3840x2160 (60p/50p/30p/25p), 1920x1080 (60p/50p/30p/25p/24p/i60/i50), 1280x720 (60p/50p/30p/25p/24p)
    4K Live Streaming
    Yes
    Live Streaming Audio Channels
    2
    Input / Output Connections
    OUT HDSDI
    Yes, 3G HDSDI
    OUT HDSDI Format max.
    1080/60p,50p
    OUT HDMI
    Yes
    OUT HDMI Format max.
    2160/60p, 50p
    OUT Audio Line
    Yes, 1 times 3.5mm mini jack
    IN Audio AUX
    Yes, 1 times 3.5mm mini jack
    Build in Microphones
    Yes
    PTZ Serial Interface RS-232C in/out
    Yes, over 8 PIN mini DIN
    PTZ Supported Protocols
    Serial, PelcoD, IP JVC, IP others
    Power and Enviroment Spec´s
    Power DC
    Yes, 12 Volt or 42V to 57V POE+ over Network LAN
    Power consumption
    12W
    Operation Temperature in Celsius degrees
    0 to 40
    Storage Temperature in Celsius degrees
    -40 to 60
    Included Accessories
    AC/DC adapter
    Yes
    Cable 1
    Yes, Power Cable
    Cable 2
    Yes, RS232 Cable
    Instructions
    Yes, User Manual, Warranty Card
    Remote Control unit
    Yes, IR controller
    Ceiling mount bracket
    Yes
