RM-LP5G
×
COMPACT JOYSTICK PTZ CONTROLLER
RM-LP5G
This compact joystick controller connects to your network and provides complete IP control of cameras in your facility or anywhere in the world through the Internet.
- 5 camera / 5 preset PTZ camera operation with 2-axis joystick and zoom bridge controls
- Supports VISCA, UDP, PELCO P/D control protocols over RS422, RS485, RS232 and IP
- 4-color LED multi-screen display supports easy setup and operation
Technical Specifications
Technical Specifications
Control Support for
- Camera model:
- KY-PZ200 Series
- Camera model:
- KY-PZ400 Series
- Camera model:
- KY-PZ510 Series
- Max Control of X Cameras:
- 5 Unit (s)
Controlled Operations
- PAN
- YES
- TILT
- YES
- SPEED PAN/TILT
- YES
- ZOOM
- YES
- FOCUS
- YES
- AE Level
- YES
- Shutter
- YES
- GAIN
- YES
- IRIS
- YES
- White Balance
- YES
- Preset Position (store/delete)
- YES
- Camera´s Menu Control call
- YES
Input / Output Connections
- Ethernet
- RJ 45
- RS232
- Yes
- RS485/422
- Yes
- USB
- Service Terminal
Power and Environment Information
- Power
- DC12 Volt
- Power consumption
- 3.6W (max)
- Operation Temperature in Celsius
- 0 degree to 40 degree
- Storage Temperature in Celsius
- -20 degree to 60 degree
Physical Information
- Dimension
- W:244mm - H:48mm - D:164mm
- Weight
- 1.1 Kg
Included Accessories
- AC Adapter
- YES
- Instruction Doc:
- YES
- Others
- Phoenix Contact 4 pin 3.81mm Terminal
General Editing note
- Note :
- Simulated pictures.The values for weight and dimensions are approximate.E.&O.E. Design and specifications subject to change without notice.
