Projectors

LX-UH1B

MENU

DLP Projector

LX-UH1B

$2,499.95

The LX-UH1 is a high-performance 4K UHD/HDR home theater projector with compact design and wide lens shift for easy installation; also thanks to its 2,000-lumen output there is no need to always pull the curtain. This projector is ideal for all your broadcast, streaming and BD viewing.




COUNTERFEIT JVC PRODUCTS ARE BEING SOLD WITHIN THE UNITED STATES.

  • Compact design for installation convenience: just 33 cm by 33 cm, and less than 13.5 cm high (Approx. 13" by 13", and 5.3" in height)
  • Compatible with HDMI standards (4K/60P 4:4:4) and HDCP 2.2
  • 4K input specs: Supports 4K/60p, 4:4:4/36bit, 4K/60p 4:2:2/36bit, and 4K/24p 4:4:4/36bit signals - for more vivid colors and subtle gradations
  • 4K resolution (3840 x 2160) achieved
  • Connectors: PC in, HDMI 1 with HDCP2.2 support, HDMI 2, USB Mini B, Trigger (12 V), USB Mini A (1.5 A power supply), and RS-232
  • 0.47-inch DMD for bright high-definition 4k images
  • Dynamic contrast ratio: 100,000:1
  • Brightness: 2,000 lm
  • 100% coverage of Rec. 709 gamut
  • Wide lens shift function: +/-60% vertical, +/-23% horizontal
  • 1.6x high-resolution lens
  • HDR (high dynamic range) for more realistic, dynamic images
  • HDCP2.2 compatibility with HDMI 1 terminal to support video-streaming services and copyright-protected content including UHD BD discs
  • Available in 2 colors (black and white)
Technical Specifications
Manuals
Technical Specifications
Device
0.47" DMD (1920 x 1080)
Resolution
3840 x 2160
Lens shift function
+/-60% vertical & +/-23% horizontal, motorized
Light source lamp
NSH 240 W
Lamp life
Approx. 4,000 hours in normal mode, 10,000 hours in eco mode
Brightness
2,000 lm
Contrast Ratio
Dynamic: 100,000:1
PC
1 (D-sub 15pin)
RS232C
1 (D-sub 9-pin)
General
Noise level
29 dB (Eco)/ 33 dB (Normal)
Power requirement
AC110 V-240 V, 50/60 Hz
Dimensions: W x H x D, mm
333 x 135 x 331.5 mm
Dimensions: W x H x D, inches
13-1/8 x 5-5/16 x 13-1/16
Weight, kg
4.8
Weight, lbs
10.56
Manuals
Instruction manual Dutch 2018 4.33MB View Download
Instruction manual English 2018 4.35MB View Download
Instruction manual French 2018 4.31MB View Download
Instruction manual German 2018 4.34MB View Download
Instruction manual Italian 2018 4.33MB View Download
Instruction manual Russian 2018 4.18MB View Download
Instruction manual Spanish 2018 4.29MB View Download
