DLA-NP5

MENU

Home Projector

DLA-NP5 NEW

CAD 8,999.99

JVC DLA-NX7 D-ILA projector is wrapped in a whole new design, which is packed with the latest projection features. For instance with the new 0.69-inch native 4K D-ILA device, the projector can produce high-definition native 4K resolution (4096 x 2160) images from its all-glass 65 mm diameter lens system. HDR10 content can be projected at optimum quality with Auto Tone Mapping function, and the new Frame Adapt HDR function, which analyzes HDR10 content frame-by-frame and automatically performs frame adjustment for optimal image projection. Combining brightness of 1,900 lm, dynamic contrast ratio of 800,000:1, and 18-bit equivalent gamma accuracy for smooth gradation, the projector reproduces life-like images close to reality as we perceive with our eyes. Renewed Clear Motion Drive together with Motion Enhance, which optimizes the D-ILA driving device according to image movement, significantly reduce blur compared to other projectors.


  • logo: 4K
  • logo: D-ILA
  • logo: HDR
  • logo: HDR10+
  • logo: FILMMAKER MODE
  • logo: 3D

8K. LASER. HDR.
The ART OF PROJECTION

Essential all-glass lens to depict all the data in the 8K/4K images

The high-end DLA-NZ9 (RS4100) is equipped with an 18-element, 16-group all-glass lens featuring a full aluminium lens barrel*1. To project highresolution 8K images to every corner of the screen, the projector incorporates five ED lenses calibrated for differences in the R/G/B refractive index to reduce chromatic aberration and colour fringing when lens shift kicks in to deliver precise reproduction of 4K- or 8K-resolution*2 projection.

*1: 65 mm diameter, 17-element, 15-group all glass lens is featured on the DLA-NZ8 (RS3100), NZ7 (RS2100) and NP5 (RS1100) models.
*2: Resolution varies depending on the model.

HDR10+ Support allows a choice for two dynamic
tone mappings

When it comes to reproducing the rich video information of HDR content including the extended brightness range, BT.2020 wide colour gamut and 10-bit gradation, rely on one of the new D-ILA projectors. New models support all HDR formats including HDR10 for Blu-ray and streaming, HLG for broadcasting, and the latest HDR10+ signal format with dynamic metadata compatibility.

JVC projectors are compatible with the two dynamic tone mappings of HDR10+ and Frame Adapt HDR. HDR10+ contains the metadata of the producer's intentions for each scene, Frame Adapt HDR instantly analyses the peak brightness in HDR10 content using an original algorithm. Ensuring you can watch any HDR content in optimal picture quality.

4K120p input ideal for Low Latency Mode

Because these projectors are equipped with 4K120p input, signal latency is infinitesimal, making it effective when displaying high frame-rate gaming content on large screens. What’s more, Low Latency Mode reduces delay in displaying PC signals and games, and improves response to the users’ rapid operations.

  • New 0.69 inch 4K D-ILA (4096 x 2160) device x 3
  • High-definition display at 4K resolution (4096 x 2160)
  • Exceptionally bright 1,900 lm means bright, high-resolution images
  • Deep Blacks are realized by a High Native Contrast Ratio of 40,000:1 (Dynamic Contrast Ratio 400,000:1)
  • 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 4K120P input signals
  • 17-element, 15-group all-glass 65mm diameter high-quality lens
  • Compatible with the two dynamic tone mappings of HDR10+ content and Frame Adapt HDR with Theatre Optimizer
  • As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation
  • Theater Optimizer** function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping.
  • The projector automatically reproduces HDR10+ content based on the metadata of the producers intentions for each scene.
  • For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
  • Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
  • Compatible with Hybrid Log-Gamma that is expected to be used widely in future broadcasting
  • 10 Installation Modes centrally manages various settings related to installation to enjoy video best suited for each environment
  • Settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, Pincushion, and Aspect; stored installation modes for various environments can be called up.
  • Renewed Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
  • Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
  • Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
  • Colour Management System with 6-axis Matrix
  • Auto-Calibration Function using an optical sensor*** is capable of optimizing essential elements in the image, including colour balance, gamma characteristics, colour space and colour tracking
  • ISF C3 (Certified Calibration Controls) mode to reproduce excellent picture quality optimized for specific environments.
  • Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter
  • **Theater Optimizer can be activated only when the projectors picture mode is set to Frame Adapt HDR.
  • ***Exclusive JVC software installed in PC and optical sensor are required. Please visit the JVC website for details.
Technical Specifications
Product Support
Technical Specifications
Device
0.69-inch Native 4K DILA Device (4096x2160) x3
Resolution
4096 x 2160
Lens shift function
+/-80% vertical & +/-34% horizontal, motorised in 16:9 aspect mode
Light source lamp
NSH 265 W
Lens
All-glass lens with 65 mm diameter
Zoom
2X zoom & focus, motorised
Lamp life
Approx. 4500 hours in Low mode
Brightness
1,900 lm
Contrast Ratio
Native: 40,000:1, Dynamic: 400,000:1
Video format
Digital: 480p, 576p, 720p 60/50, 1080i 60/50, 1080p 120/100/60/50/30/25/24, 2048x1080 120/100/60/50/30/25/24, 3840 x 2160p 120/100/60/50/30/25/24, 4096 x 2160p 120/100/60/50/30/25/24
HDMI
VGA/ SVGA/ XGA/ WXGA/ WXGA+/ SXGA/ WSXGA+/ UXGA/ WUXGA/ WQHD (60)/ WQHD (120)
HDMI
2 (48Gbps, HDCP2.3, no support for CEC)
3D sync
1 (Mini DIN 3-pin)
Trigger
1 (mini jack, DC12V/100mA)
RS232C
1 (D-sub 9-pin)
LAN
1 (RJ-45)
Service
1 (USB Type A) (for firmware update)
3D
Frame packing
720p 60/50, 1080p 24
Side-by-side
720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & bottom
720p 60/50, 1080p/24
General
Noise level
24dB (in Low Mode)
Power requirement
AC100V-240V, 50/60Hz
Projector in use
420 W
Standby
Normal: 1.5W, Eco-mode: 0.3W
Networked standby
1.3 W (LAN), 1.0 W (RS-232C), 1.3 W (LAN and RS-232C)
Switchover time
20 min. (To standby or networked standby; default)
Dimensions: W x H x D, mm
500 x 234 x 495
Weight, kg
19.2
